7112 Rectangular Open End Fitting 9 x 12

The 7112 Rectangular Open End Fitting is a forged interchangeable end fitting designed for use with torque wrenches featuring a 9 x 12 mm rectangular drive connector. It is intended for difficult assembly applications and can be easily replaced.

Specifications:

Product item Spanner size Drive connector Head width Depth gauge
7112-07 7 mm 9 x 12 mm 20 mm 17.5 mm
7112-08 8 mm 9 x 12 mm 21.5 mm 17.5 mm
7112-09 9 mm 9 x 12 mm 23 mm 17.5 mm
7112-10 10 mm 9 x 12 mm 24.5 mm 17.5 mm
7112-11 11 mm 9 x 12 mm 26 mm 17.5 mm
7112-12 12 mm 9 x 12 mm 27.5 mm 17.5 mm
7112-13 13 mm 9 x 12 mm 29 mm 17.5 mm
7112-14 14 mm 9 x 12 mm 31 mm 20 mm
7112-15 15 mm 9 x 12 mm 33 mm 20 mm
7112-16 16 mm 9 x 12 mm 35 mm 20 mm
7112-17 17 mm 9 x 12 mm 37 mm 20 mm
7112-18 18 mm 9 x 12 mm 39 mm 20 mm
7112-19 19 mm 9 x 12 mm 41 mm 20 mm
